ZMW24
24GHz Radar Sensor for Barrier and Gate /Replacement of Loop Detector /Parking Garage Parking Lot Security
- Wide Voltage Design, +9V ~ +24V
- Precise identification and differentiation of people and vehicles
- Adaptable to different types of barrier gates in barrier systems
- Seamless integration with barrier systems, easy to install
- Long lifespan, can be used for over 10 years
- No need for ground cutting, low maintenance cost
- Unaffected by strong light, rain, snow, fog, and other environmental conditions
- IP67 standard, waterproof sealed structure, impervious to water and dust
MW24 Specification
| Scope of application | Straight bar gate |
|---|---|
| Input voltage | DC12V 150mA |
| Working frequency | 24-24.5GHz |
| Modulation mode | FMCW |
| Transmit power | 10-1 5dBm |
| Horizontal beam | < 30℃ |
| Vertical beam | < 17℃ |
| Detection distance | 1-6 meters, +-0.1 meters |
| Operating temperature | -40℃~+85℃ |
| Degree of protection | IP67 |
